SC-1200 (1200W)

1200W Inverter Charger: SC-1200 Model

Bi-directional inverter and charger.
Automatically various operation mode:
1. Inverter mode.
2. Charger mode.
3. Power Sharing.
4. Power Generation.
5. Power Support.
3-stage charging function.
Wide working temperature range: -20℃ ~ 40℃
UL & CE Certified. Such as UL458 with the marine supplement, UL1741, FCC approved.
-20^oC~40^oC full load operation without derating.
High Power density (1200W @4.55kg, 2000W @ 6 kg).
Inverter charge remote controller: CR-20C / CR-16B / CR-8 (Optional)
Charging Compensation via The Temperature Sensor (optional).

MODEL	SC-1200-112, SC-1200-124, SC-1200-212, SC-1200-224
Main Features	◎ All in one design: Bi-direction inverter and charger ◎ Certified by UL458 with marine supplement ◎ Compact design
AC Output Voltage	100/110/115/120VAC ± 3% ; 200/220/230/240VAC ± 3%
Rated Power	1200VA
Surge Power	Load 101%~115% (1 Min) / Load 116%~200% (3 sec) ; 2400 VA (2 Sec)
Output Waveform	Pure Sine Wave (THD < 5% @ 12.5V/25V/115VAC, linear load) / (THD < 3% @ 12.5V/25V/230VAC, linear load)
Frequency	50/60 Hz ± 0.3 Hz (User-selectable)
DC Output Voltage	─
DC Output Voltage Range	─
DC Input Voltage	12V; 24V
DC Input Voltage Range	10.5 ~ 16.5 VDC; 21 ~ 33 VDC
Efficiency	>88%
Operating Temperature	-20℃ ~ 50℃, Power De-rating from 50°C to 60°C
Storage Temperature	-30 ℃~70 ℃
Safety	UL458 & Supplement SA / UL1741 , FCC class A
Dimension (WxHxD)	251 x 116 x 386mm
Weight (Net)	4.55Kg
